Melamine Finish Cabinets

melamine finish cabinets



OEM/ODM	Support Customized Anything You Need, Like Design/Color/Material/size
Carcase material	Solid wood/Particle board/Plywood/MDF/Stainless Steel/Support Customized
Carcase thickness	16-19mm/optional
Carcase color	White or custom color
Door material	Solid wood/MDF/Plywood/Particle board/Glass/Stainless Steel/Support Customized
Door finish	Acrylic/Lacquer/UV/PVC/Melamine/Solid Wood/Stainless Steel/Support Customized
Door thickness	16-19mm
Countertop	Granite, marble, quartz, artificial stone, or customized
HardWare	Blum Or Others Is Available
Color	Cuztomized
Size & design	Custom size & Design
	1.Full set of kitchen cabinet including counter top, sink, faucetand other accessories
	2.Free and professional design, quick quote
Features	3.Kinds of materials/finishes/colors choices
	4.Customized style and detail notice to give you a dream kitchen
	5.Water proof and environment friendly boards
	6.Stable quality and rich experience in oversea projects





• A paper sheet impregnated with melamine-formaldehyde resin is thermally fused under high pressure onto a substrate (usually MDF or particle-board).
• Result: a thin, hard, non-porous "skin" that can be printed any colour or pattern-wood grain, concrete, solid colour, even high-gloss.
• Think of it as a factory-applied, built-in laminate that's inseparable from the board.





• Fastest-growing price segment in China & SE Asia-accounts for ~42 % of factory-made cabinet doors.
• Textured melamine (3-D wood-grain embossing) is now the default "budget Shaker" look in North American big-box stores.
• Colour leaders: warm white, greige, sage green, matte black, and wire-brushed oak print.





• Price: 30–50 % cheaper than painted MDF, 60 % cheaper than solid wood.

• Consistent finish: no brush marks, no colour shift between batches.
• Ready-to-install: no primer, no spray booth, no cure time-doors arrive finished.
• Cleanability: non-porous; ketchup, coffee, turmeric wipe off with soap & water.
• Scratch & abrasion: good for vertical surfaces (doors/drawers) in normal household use.
• Eco-credit: resin paper uses recycled wood fibres; no VOC on-site.



• Moisture vulnerability: exposed particle-board edges can swell if water sits (common near sink doors).

• Edge-chip risk: a dropped pot can flake the 0.2 mm skin; repair is almost invisible.
• Heat threshold: ~150 °C (302 °F); direct contact with a hot baking sheet will blister.
• Design limits: sheet width max 1 220 mm (4 ft); very wide doors need centre joint or PVC edge strip.
• Cannot be re-painted easily; sanding burns through the skin.





• Rental apartments, first-time homeowner budgets, laundry or garage storage.
• Modern flat-panel kitchens (slab or thin-frame Shaker).
• Large developments needing identical finish across hundreds of units.





• Steam-cooker / combi-oven enclosures without ventilation.
• Kid-heavy households where doors double as basketball backboards.
• Custom curved or routed profiles (skin will crack on tight bends).





1.Specify PVC edge-banding 1 mm thick on all four edges; seals out moisture.
2.Use plywood core instead of particle-board for sink-base cabinets.
3.Add adhesive edge-sealant (clear polyurethane) along inside hinge holes.
4.Install heat shields on cabinets flanking ovens (cheap aluminium sheet).
5.Clean with mild dish soap only; abrasive pads micro-scratch the surface and dull gloss over time.\





• Daily: dry micro-fiber dust.
• Weekly: damp cloth + 1 tsp dish soap; dry follow-up.
• Grease film: 50/50 white vinegar & water on cloth (never spray direct).
• Baked grime: baking-soda paste 5 min, wipe, rinse, dry.
• NO: Magic Erasers, bleach, citrus cleaners, steel wool.





Melamine finish cabinets deliver a factory-perfect, budget-friendly face for contemporary kitchens. Specify them in dry, medium-traffic zones, demand 1 mm PVC edge-banding, and they'll look fresh for 10–15 years. For steam-bath conditions or high-impact abuse, step up to laminate-on-plywood or painted MDF. Choose melamine when cost, speed, and a flawless flat finish outweigh the need for heavy-duty repairability.





melamine cabinet carcass



Melamine Cabinet Carcass – 2025 Buyer's Technical Guide
(What it is, how it's made, real-world durability, cost vs. plywood, and specification tips you can copy into your RFQ)





A melamine cabinet carcass is the box (sides, bottom, top, shelves, back) that forms the structural skeleton of kitchen, bath or wardrobe units.

• Skin: thermally-fused melamine-impregnated paper (≈ 0.2 mm) on both faces.
• Core: most commonly 16 or 18 mm particle-board (PB) or medium-density fibre-board (MDF); occasionally plywood for upgraded lines.
• Edge: 1–2 mm PVC or ABS banding applied by hot-melt PUR adhesive for moisture seal and finished look.



• > 60 % of factory-built kitchen cabinets shipped from China, Vietnam and Turkey use melamine-faced chipboard (MFC) carcasses.
• Lead time: 25–35 days FOB for custom sizes; 3-day ex-stock for modular European 32 mm system boxes.
• Sheet size standard: 2 800 × 2 070 mm; yields ± 18 running metres of 600 mm deep base cabinets.







• Density: 680–720 kg/m³ (PB); 750–800 kg/m³ (MDF).
• Screw withdrawal: PB ≈ 45 N/mm; MDF ≈ 55 N/mm; birch ply ≈ 75 N/mm.
• Surface hardness (EN 1534): ≥ 3.5 N/mm² – resists household keys/coins.
• Flame spread (ASTM E84): Class C (lower than plywood Class B).
• Formaldehyde: E0 ≤ 0.05 mg/m³; CARB P2 / TSCA Title VI compliant boards are now mainstream.



Good for: dry kitchens, bedrooms, laundry rooms, offices.

Risk zones:

• Sink base: prolonged standing water wicks into uncovered bottom edges → swelling.
• Dishwasher return: steam venting directly onto end panel.
• Mitigations: specify 1 mm PVC edge on all 4 edges, silicone-seal bottom rail, or upgrade sink carcass to plywood/melamine.





*Fair = acceptable if all edges sealed and no direct water contact.



• Solid colours: 200+ stock (RAL & NCS matched).
• Wood prints: synchronised texture (wire-brushed oak, walnut, ebony) pairs with PET or acrylic fronts.
• Gloss levels: matte (5–8 GU), satin (15–25 GU), high-gloss (80+ GU) acrylic or UV top-coat available.
• Custom print: stone, concrete, fabric weave-MOQ 50 sheets





• Blade: 80-tooth TCG, negative hook, 3 000–4 000 rpm.
• Score first: 0.5 mm depth pass → full cut prevents blow-out on bottom face.
• Edge-banding: use 0.8–1 mm PVC, apply 200 °C, pressure 3 bar, feed 8 m/min.
• Pilot holes: 2.5 mm for 4 × 35 mm confirmat screws; countersink to avoid skin fracture.







E0 / formaldehyde boards emit < 0.03 ppm formaldehyde-below WHO indoor guideline.
100 % recycled wood fibres in PB core; skins are paper-based (renewable).
Take-back programmes in EU convert old MFC into particle-board filler-circular use.



✓ Fast-track installs (hotel, multi-family) – ready-finished boxes.
✓ Dry climates / controlled indoor humidity.
✗ Specify plywood or BWR board for: steam ovens, dish-washer returns, outdoor kitchens, or when client demands 25-year+ zero-swell warranty.



Melamine-faced chipboard/MDF carcasses give you a factory-perfect, colour-matched, low-cost box that's dimensionally stable and eco-friendlier than site-sprayed alternatives. Seal the edges, keep liquids off the bottom rail, and you'll enjoy a sleek, modern cabinet system for 15+ years-at roughly half the cost of plywood.
